Standard 11″ left and right cast iron extension wings provides the largest table surface in its class
Poly-V drive belt system delivers quiet, efficient operation
Rail-mounted magnetic switch is easy to reach and provides overload protection
Enclosed cabinet with built-in sealed storage drawer.
Deluxe miter gauge with adjustable positive stops and large soft grip handles provides large crosscutting capacity and accurate miters.
Hinged motor cover on cabinet gives quick access to the motor and belts.
Heavy-duty chrome plated handwheels contribute to smooth trunnion/arbor movement.
Built-in 4″ dust collection port.
Precision ground high luster cast iron table tops with front edge bevel for hassle-free workpiece positioning.
Left tilt, Wide stance heavy-duty trunnion for stability and smooth blade positioning.
Independent leaf safety guard protects operator from blade while cutting, even at 45° tilt.
Powder coated paint for a long-lasting, chip-resistant finish.
Arbor wrench.
SPECIFICATIONS :
Style (Type): Cabinet
Blade Diameter (In.): 10
Arbor Diameter (In.): 5/8
Arbor Speed (RPM): 4300
Dust Collection Minimum CFM Required (CFM): 350
Dust Port Outside Diameter (In.): 4
Maximum Depth of Cut (In.): 3
Maximum Depth of Cut at 45 Degrees (In.): 2-1/8
Maximum Rip Left of Blade (In.): 13
Maximum Rip Right of Blade (In.): 30
Table in Front of Saw Blade at Maximum Depth of Cut (In.): 10
Maximum Diameter of Dado (In.): 8
Maximum Width of Dado (In.): 13/16
Table Type: Cast Iron
Table Size (L x W) (In.): 29 x 20
Table Size with Extension (L x W) (In.): 29 x 42
Miter Gauge Type : Deluxe
Motor Power (HP): 3
Motor Phase (PH): 1
Motor Voltage (V.): 230
Motor Amps: 14.5
Prewired Voltage (V.): 230
