Length Comparator
Product Code : EL-CTLE-10345
Length Comparator (code EL-CTLE-10345) is a measuring frame for length measurements on cement and mortar specimens of different lengths. It has a two-column steel frame with an adjustable top anvil and a digital gauge of 12.5 × 0.001 mm, measures 180 × 180 × 490 mm and weighs about 10.5 kg, while reference rods are ordered separately to suit the specimen length.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Use | Length measurements, mainly on cement and mortar specimens of different lengths |
| Frame | Two-column steel frame |
| Top anvil | Adjustable to suit the specimen length |
| Gauge | Digital, 12.5 × 0.001 mm |
| Reference rods | Not included; ordered separately to suit the specimen length |
| Dimensions | 180 × 180 × 490 mm |
| Weight | Approx. 10.5 kg |
| Standards | EN 1367-4, UNI 8147, UNI 8148, EN 12617-4, EN 12808-4, ASTM C151, ASTM C490, UNI 8520:22, UNI 6687, EN 680 |
| Product code | EL-CTLE-10345 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Length Comparator Used For?
Shrinkage, expansion and similar tests follow small changes in the length of a hardened specimen over days or weeks, so every reading has to be taken the same way. The top anvil is set to the specimen length, and the digital gauge is zeroed against a reference rod of matching length. The specimen is then placed between the anvil and the gauge and its reading recorded; repeating this at each test age shows how much it has grown or shortened, worked out against its original gauge length. The gauge reads to 0.001 mm, so small movements are picked up.
What to Specify When Ordering
- Quantity — the number of comparators required.
- Reference rods — the reference rods needed for the specimen lengths to be measured, as they are ordered separately.
Frequently Asked Questions
Which specimens can the Length Comparator measure?
It is used for a range of length measurements, mainly on cement and mortar specimens of different lengths, with the top anvil adjusted to suit each specimen length.
What gauge is fitted?
A digital gauge of 12.5 × 0.001 mm is fitted to the two-column steel frame, so changes in specimen length are read to 0.001 mm.
Are reference rods included?
No. Because specimens come in different lengths, the reference rods are not included and are ordered separately to match the lengths that will be measured.
What is a reference rod used for?
A reference rod of known, stable length is placed in the frame before the specimens to zero or check the gauge, so that every reading starts from the same point.
What are its dimensions and weight?
The comparator measures 180 × 180 × 490 mm and weighs approximately 10.5 kg, with the gauge mounted on its two-column steel frame.
Which standards are listed for it?
The standards listed are EN 1367-4, UNI 8147, UNI 8148, EN 12617-4, EN 12808-4, ASTM C151, ASTM C490, UNI 8520:22, UNI 6687 and EN 680.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Length Comparator at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its cement testing equipment such as Vicat and Blaine apparatus, moulds, mixers and curing equipment go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
