Computerized Axial Flow Pump Test Rig
Product Code : EL-TMLE-10683
Quick Answer: The Computerized Axial Flow Pump Test Rig is a trainer built around an axial-flow (propeller) pump, in which the pumping medium flows through the impeller in the axial direction and pressure is built up by the propeller-blade (aerodynamic) principle rather than by centrifugal force. Because these pumps are not self-priming and must stay fully covered by the pumping medium, they are best suited to applications needing high flow rates with a small head, such as drainage systems, wastewater treatment plants and cooling water supply systems. The trainer reproduces this behaviour with a closed water circuit, digital measurement displays and USB-based data acquisition so students can measure and analyse the pump’s real performance.
The trainer combines the axial propeller pump, a tank and pipelines with generously designed pipe cross-sections, powered through the Universal Drive and Brake Unit, and its closed water circuit lets it run independently of the water system. It is fitted with pressure-measuring elements at the pump inlet and outlet, a temperature sensor and an electromagnetic flow meter, with all measured values shown on digital displays and transmitted simultaneously via USB to a PC, where they can be analysed using the included software.
FEATURES:
Closed water circuit
Digital display of flow rate, pressure and temperature
Determination of the efficiency
Determination of the head
Determination of the system characteristics
Determination of the pressure/volume characteristics
Determination of the power requirement of the pump
Determination of the hydraulic power
SPECIFICATIONS:
Pump :
Output: 1000W at 1000min-1
Max. Flow rate: 700L/min
Max. Head: 1,75m
Tank: 160L
Measuring ranges :
Flow rate: 0…1200L/min
Temperature: 0…100°C
Pressure (outlet): 0…0,6 bar
Pressure (inlet): ±1bar
230V, 50Hz, 1 phase
DIMENSIONS AND WEIGHT:
LxWxH: 1110x800x1380mm
Weight: approx. 154kg
For this and other turbo machinery lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India.
