Miniature Vertical Milling Machine
Product Code : EL-CACLE-10880
Quick Answer:
The Miniature Vertical Milling Machine is a bench-scale vertical mill/drill trainer powered by a 550-watt DC motor with variable speed from 20 to 2500rpm, featuring a tilting column that allows drilling and milling at up to ±90° from vertical and a T-slotted, metric-graduated compound working table for clamping workpieces. It comes with a 13mm chuck accessory kit, adjustable feed speed, a digital readout display, adjustable gibs and stops on the table, and a rack-and-pinion feed for drilling operations. It offers a 13mm drilling capacity, 30mm face milling capacity, 16mm end milling capacity, 250mm cross travel, and a spindle taper of MT3, all on a robust construction with an extra-wide cross table and a start/stop switch that incorporates an emergency stop.
Overview:
It features a 550-watt motor with variable speed drive. The working table with T-slots enables clamping of work pieces and has metric graduated compound scales, and the machine also incorporates a tilting column which allows drilling and milling of the work piece at ±90° from vertical. This machine is DC motor driven, with variable speed from 20-2500rpm, and its feed speed can be adjusted according to the requirements of different work pieces. It is supplied with a 13mm chuck accessory kit for adjusting and setting.
FEATURES:
Digital readout display
Head swivels ±90° vertically
Adjustable gibs on table precision
Adjustable stops on table
Chuck arbor bolt provides tightening of drilling chuck through the spindle
Rack and pinion feed for drilling operations
Safety guard with micro switch according to EU-requirements
Straight forward gear drive mechanism
Robust construction
Extra wide cross table
Available in metric lead screws
START / STOP switch incorporates emergency STOP
SPECIFICATION:
Motor power: 550W
Drilling capacity: 13mm /0.51?
Face milling capacity: 30mm /1.18?
End milling capacity: 16mm/0.63?
Longitudinal travel: 100mm/3.94?
Cross travel: 250mm /9.84?
Max distance spindle to table: 220mm /8.66?
Spindle taper: MT3
T-slot: 10mm /0.39?
Spindle speed: 20 – 2500rpm
Spindle rotary angle: -45°~+45°
X-Axis Travel Bed: 300mm/11.81?
Y-Axis Travel Bed: 140mm/5.51?
Z-Axis Travel Bed: 220mm/8.66?
Spindle stroke: 200mm /7.87?
Working table size: 460 x 112mm/18.11? x4 .41?
Table Size: 460*110mm/18.11?x4.33?
DIMENSIONS AND WEIGHT:
Machine Dimensions (L x W x H) approx.: 680 x 400 x 800 mm
Machine Weight approx.: 180 kg
