Tamping Bar
Product Code : EL-CTLE-10319
Tamping Bar (code EL-CTLE-10319) is a steel bar used in the concrete testing laboratory to compact fresh concrete into cube moulds by hand. It has a square section of 25 mm and a length of 380 mm, and a handle is fitted so the operator can grip it while working the concrete in the mould.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Material | Steel |
| Cross-section | Square, 25 mm |
| Length | 380 mm |
| Handle | Fitted |
| Use | Compacting concrete into cube moulds by hand |
| Product code | EL-CTLE-10319 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Tamping Bar Used For?
Cube specimens give a fair strength result only when the concrete in them has been compacted fully, without pockets of trapped air. With the cube mould filled in layers, the operator holds the bar by its handle and works its square 25 mm end down through each layer in turn, spreading the strokes over the area before adding the next layer. Its 380 mm length and square section set it apart from the round 16 mm, 600 mm tamping rod listed alongside it; where a test method names the compacting tool, the method decides which of the two is used.
What to Specify When Ordering
- Quantity — the number of tamping bars required.
- Test method — the test method that specifies the compacting tool, so that the bar or the round tamping rod is matched to it.
Frequently Asked Questions
What job does the Tamping Bar do?
The operator grips it by the fitted handle and uses it to work fresh concrete down into cube moulds, compacting each layer in the concrete testing laboratory.
How big is the tamping bar?
The bar has a 25 mm square cross-section and a length of 380 mm, and it is made of steel with a handle fitted.
How does the bar differ from the round tamping rod?
The bar is square, 25 mm across and 380 mm long, with a handle; the round tamping rod is 16 mm in diameter, 600 mm long and rounded at both ends. Both are steel.
Which tool should be chosen, the bar or the rod?
Where the test method in use specifies the compacting tool, that method decides; naming it in the enquiry lets the matching tool be quoted.
How is an enquiry for the Tamping Bar sent?
Use the Add To Cart enquiry button on this page or the contact page, giving the number of bars and where they are to be delivered.
OEM Manufacturer
Buyers of the Tamping Bar deal directly with its maker, Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd), whose works are at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests concrete testing equipment, from workability apparatus and specimen moulds to compression and flexure machines, supplies engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and builds to institution-specific requirements on request. Tender details are on the Tenders/OEM page.
Related Concrete Testing Equipment
- Concrete Cube Mould — cast iron cube mould with base plate, made in metric and inch sizes.
- Tamping Rod — steel rod, 16 mm diameter and 600 mm long, rounded at both ends for cube compaction.
- Straight Edge — flat steel strike-off bar, 1 × 12 in, for cube, cylinder, slump cone and air meter work.
See the full Concrete Testing Lab Equipment range or all Civil Engineering Lab Equipment.
Request a Quote
For this and other concrete testing lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. Quotations are given on request: send the number of tamping bars and the test method that names the compacting tool and your delivery location through the contact page, or add the Tamping Bar to the enquiry cart from this page.
