Straight Edge
Product Code : EL-CTLE-10320
Straight Edge (code EL-CTLE-10320) is a flat steel bar used to remove excess material when moulding cube and cylinder specimens and when carrying out slump cone and air meter tests. It measures 1 in × 12 in (2.5 × 30.4 cm).
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Type | Flat bar |
| Material | Steel |
| Dimensions | 1 in × 12 in (2.5 × 30.4 cm) |
| Use | Removing excess material when moulding cube and cylinder specimens; slump cone and air meter tests |
| Product code | EL-CTLE-10320 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Straight Edge Used For?
Many concrete tests depend on a mould or container being filled exactly to its rim, so the surplus concrete standing above the top has to be removed to leave a flat, level surface. After the cube or cylinder mould, or the air meter bowl, has been filled and compacted, the straight edge is laid across the rim and drawn over it to strike off the excess, and it serves the same purpose in slump cone tests. The flat steel bar is 1 in × 12 in.
What to Specify When Ordering
- Quantity — the number of straight edges required.
Frequently Asked Questions
What is the Straight Edge used for?
It is used to remove excess material when moulding cube and cylinder specimens, and when conducting slump cone and air meter tests on fresh concrete.
What size and material is the straight edge?
It is a flat bar made from steel, measuring 1 in × 12 in, which is 2.5 × 30.4 cm.
Why is excess concrete struck off with a straight edge?
Striking off leaves the concrete level with the rim of the mould or container, so the specimen has a flat top and the container holds a known volume.
OEM Manufacturer
The Straight Edge is made by Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) at its works at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests concrete testing equipment, from workability apparatus and specimen moulds to compression and flexure machines for engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and can build equipment to an institution's own requirements. Tender and OEM enquiries are handled through the Tenders/OEM page.
