Metallurgical Inverted Microscope
Product Code : EL-STLE-10566
Quick Answer: The Metallurgical Inverted Microscope offers 40x-1000x magnification for surface studies via incident halogen illumination, featuring a rigid stand with ball bearing guide ways, an inclined binocular tube with interpupillary adjustment, a quadruple revolving nosepiece, and a large graduated mechanical stage with co-axial X-Y controls.
Rigid & stable stand with well-counted large modular base.
Ball baring guide ways and slides provides extra smooth movement
Inclined Binocular tube with interpupillary adjustment for strain free Microscopic studies.
Coarse & fine adjustments by independent knobs.
Incident halogen illumination with variable control for surface studies
SPECIFICATIONS:
Magnification: 40x–1000x
Illumination Incident light through Epi – illuminator with field aperture diaphragm and filter slots.
Continuously variable luminosity control through built in electronic transformer.
Eye Pieces Quadruple revolving nosepiece for quick magnification change with positive click stops for proper centering.
Compensating High eye point wide field eyepiece 10x.
Stages Large graduated mechanical stage with low drive co – axial controls for X–Y movements on the ball slides.
Objectives Achromatic Flat – field metallurgical corrected and anti mount fungus M5x, M10x, M45x, & M100x (oil).
Focusing: Co–axial focusing module with slides.
Focusing Co–axial focusing module with slides travelling on bearing guide ways.
Optical Tube Binocular
Filters Green & Blue.
DIMENSIONS AND WEIGHT:
L x W x H: 300×350 x 400 mm
Weight: 10kg
