Field Inspection Testing Kit

Field Inspection Testing Kit

Product Code : EL-STLE-10401
Quick Answer: The Field Inspection Testing Kit is designed to measure the undrained shear strength (CU) of cohesive soils. It consists of a cylindrical body with a torsional spring and three interchangeable vanes for different expected soil strengths, is driven 5-6cm into the soil and turned with a handle, can reach deeper samples using an extension rod, is supplied in a carrying case (240 x 210 x 50mm) weighing approximately 1.8 kg, and conforms to the ASTM D2573 standard.

Especially designed to measure the undrained shear strength (CU) of cohesive soils, it consists of a cylindrical body with a torsional spring and three interchangeable vanes of different sizes, used depending upon the expected strength of the soil. During operation, the vane is driven 5-6 cm into the soil and then turned with the handle. The height/diameter ratio of all vanes is 2. Deep measurements (i.e. on top of undisturbed samples) can be obtained using the extension rod (see accessories). The two units are contained in a practical carrying case.

Case dimensions: 240x210x50 mm
Weight approx.: 1.8 kg

Standards: ASTM D2573

For this and other soil testing lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India.Last Updated: September 2026
